Fibertex Geotextil
Fibertex Geotextile products offer innovative solutions for soil stabilization, erosion control, and drainage applications in civil engineering and construction projects. Their advanced technical characteristics and reliable performance make them a preferred choice for engineers seeking high-quality geosynthetic solutions.
Fibertex Geotextile Product Details and Professional Technical Analysis
Overview: Fibertex Geotextile is a leading brand that offers a wide range of high-quality geosynthetic products designed for various civil engineering and construction applications. These geotextiles are manufactured using advanced technology and superior materials to provide optimal performance and durability in challenging environments.
Key Features:
Utilizes polypropylene or polyester fibers for strength and longevity
Engineered with precise filtration and drainage properties
Options include woven, non-woven, and composite geotextiles
Resistant to UV degradation, chemicals, and biological factors
Customizable solutions to meet specific project requirements
Applications:
Soil stabilization: Fibertex Geotextiles are used to reinforce and stabilize soil in road construction, embankments, and slope protection projects.
Drainage systems: Fibertex geotextiles facilitate efficient water filtration and drainage in landfills, retaining walls, and drainage systems.
Erosion control: Fibertex products help prevent soil erosion in coastal protection, riverbank stabilization, and environmental restoration projects.
Separation and protection: Fibertex Geotextiles are employed to separate different soil layers, protect geomembranes, and enhance the performance of geotechnical structures.
Product Parameter
Project | Performance indicators | |||||||
Nominal Strength,kN/m | 5 | 8 | 11 | 20 | 24 | 28 | 34 | 50 |
Longitudinal and Transverse Tensile Breaking Strength,kN/m | ≥5.0 | ≥8.0 | ≥11.0 | ≥20.0 | ≥24.0 | ≥28.0 | ≥34.0 | ≥50.0 |
Longitudinal and Transverse Elongation At Break | 50%~90% | |||||||
Longitudinal and Transverse Tearing Strength, kN | ≥0.15 | ≥0.24 | ≥0.35 | ≥0.42 | ≥0.50 | ≥0.58 | ≥0.65 | ≥0.90 |
CBR Top Break Power, kN | ≥1.0 | ≥1.7 | ≥2.5 | ≥3.5 | ≥4.3 | ≥5.3 | ≥6.2 | ≥7.0 |
Vertical and Horizontal Grip Strength, kN | ≥0.3 | ≥0.6 | ≥0.9 | ≥1.3 | ≥1.7 | ≥2.0 | ≥2.4 | ≥3.0 |
Thicknesses, mm | ≥1.2 | ≥1.6 | ≥1.8 | ≥2.4 | ≥2.8 | ≥3.0 | ≥3.2 | ≥3.4 |
Equivalent Pore Size, ο95 mm | 0.07~0.20 | |||||||
Vertical Permeability Coefficient,cm/s | ≤2.0×10-1 | |||||||
UV Strength Retention Rate | ≥80% | |||||||
Mass Per Unit Area,g/m2 | ≥100 | ≥150 | ≥200 | ≥300 | ≥400 | ≥500 | ≥600 | ≥800 |
Quality Deviation Per Unit Area | ±5% | ±4% | ±3% | |||||
Width Deviation | ±0.5% | |||||||
Tensile Strength of Geobags At Seams,kN/m | — | ≥6.5 | ≥9.0 | ≥16.0 | — | — | — | — |
Professional Technical Analysis: Fibertex Geotextiles are known for their superior quality, reliability, and technical performance in the geosynthetics industry. The use of high-grade polypropylene and polyester fibers ensures excellent tensile strength, puncture resistance, and dimensional stability, making Fibertex products suitable for demanding engineering applications.
The precise filtration and drainage properties of Fibertex geotextiles enable efficient water flow while preventing soil clogging, ensuring long-term performance and sustainability in various environmental conditions. The versatility and customization options of Fibertex products allow engineers and designers to optimize solutions for specific project needs, enhancing overall project efficiency and longevity.
